Clear Motion Drive OFF
Clear Motion Drive ON
D-ILA device
e-shift device
Projection lens
Resolution doubles
in both directions
4K e-shift4 Technology
D-ILA optical unit
Original image
Conventional MPC technology
Multiple Pixel Control
High-quality moving images
Smooth, vivid and high-definition. 4K quality as only D-ILA makes possible.
Technologies to realise D-ILA 4K images
JVC’s e-shift technology shifts sub-frames by 0.5 pixels both vertically and horizontally to achieve
4 times the pixel density of the original content. The latest e-shift4 Technology is capable of inputting
full-spec 4K video signals including 4K60P 4:4:4 thanks to the optimised engine and newly adopted
high-power lamp. These improvements result in an even higher definition picture with more precision.
[
Original 4K e-shift Technology continues to evolve
]
D-ILA projectors feature original high-performance image processing technology, Multiple Pixel Control.
Through adoption of a new analysis algorithm, the MPC is capable of more accurate diagonal-detection
between frames for both full HD and full 4K resolution signals, delivering a thoroughly immersive high-
definition 4K image. Compared to conventional band processing, MPC achieves the utter reality of 4K
quality by detecting and processing images in a higher frequency range to achieve exceptional presence
and bokeh.
[
Multiple Pixel Control
]
Two technologies are featured on the D-ILA projector – a moving image interpolation technology
Clear Motion Drive that is compatible with 4K60P 4:4:4 signals and Motion Enhance technology that
controls the driving performance of D-ILA devices by image characteristics. Owing to the two original
technologies, the projector is capable of reducing ghosting or afterimage issues often found in fast-
moving images to reproduce a crisp and smooth moving images.
[
Exceptional motion image processing technologies for smooth video reproduction
]
The D-ILA projectors feature Low Latency Mode, which suppresses display delay for faster response
when receiving signals from PC and game consoles. These projectors are designed to satisfy not only
movie viewers but those play games on a big screen.
[
Low Latency Mode
]
